G26 Concealed Rail Lift-Sliding Window Hardware control system
| No. | Product Name | Product Code | Q'ty | Unit | Note |
| 1 | PH952 Handle | PH952.00.168WA5 | 1 | pc | 168 antibacterial sandblasted black |
| 2 | SP07 Square Shaft | SP07.12.30C021X | 1 | pc | 30mm length |
| 3 | M5*30 Phillips Head Stainless Steel Screws | B.LD.M05EA30B | 2 | pc | / |
| 4 | Slim Lift-Slide Transmission Unit | LSG71.00.12C38X | 1 | pc | / |
| 5 | Concealed Slim Edge Guiding Roller | RGP53.00.38X | 2 | pc | / |
| 6 | Concealed Slim Edge Lift-Slide Roller | LSBR72.00.031WA5 | 1 | set | / |
| 7 | Slim Lift-Slide Threaded Rod | LSS70.10.15C38 | 1 | set | Connecting rod length 1500mm, options 1100/1800/2000; required length = SW (fan width) - 398.5 |
Screen Mesh Configuration (Single Panel)
| No. | Product Name | Product Code | Q'ty | Unit | Note |
| 8 | Concealed Slim Edge Roller | R35.263103.021X | 2 | pc | / |
| 9 | Concealed Slim Edge Guiding Roller | RGP53.00.38X | 2 | pc | / |
| 10 | 200MA Handle | MAL200.16.T120WA3 | 1 | pc | / |
| 11 | MA Lock base | MALP20.01.031X | 1 | pc | / |
Sash Width：
＞500mm
Sash Height：
600mm-1500mm
Max. Sash Weight：
200kg
