SAS 90°/180° Opening Quick Assembly Tilt-turn Window Hardwarecontrol System
| No. | Product Name | Product Code | Q'ty | Unit | Note |
| 1 | PH937 Handle With Base | PH937.00.168WA5 | 1 | pc | 168 antibacterial matte black, optional 012 silver |
| SP07 Square Shaft | SP07.07.26C021X | 1 | / | External shaft length 25mm | |
| SAS Gear Case | AGC53.13.06WA4 | 1 | pc | 13mm center distance, optional 6.5mm center distance | |
| 2 | PH307 Handle Without Base | PH307.00.1T168WA3 | 1 | pc | 168 antibacterial matte black, optional 012 silver |
| SP07 Square Shaft (with screws) | SP07.07.2T26C021X | 1 | set | External shaft length 26mm, with 25mm M4 flat head screws ×2 | |
| SAS Gear Case | AGC53.13.06WA4 | 1 | pc | 13mm center distance, optional 5.5mm center distance | |
| 3 | PH402 Handle Without Base | PH402.00.168WA2 | 1 | pc | Quick assembly sliding lock case, 168 antibacterial matte black, optional 012 silver |
| Quick Assembly Gear Case | AGC53.00.031WA4 | 1 | pc | ||
| 4 | SAS Quick Assembly Tilt-turn (Left) | CTT53.00.38LWA5 | 0 | set | Opening angle 90°, load-bearing 100KG |
| SAS Quick Assembly Tilt-turn (Right) | CTT53.00.38RWA5 | 1 | set | ||
| 5 | 180°Quick Assembly Tilt-turn （Left） | CATT55.10.38LWA5 | 0 | set | Opening angle 180°, load-bearing 100KG |
| 180°Quick Assembly Tilt-turn （Right） | CATT55.10.38RWA5 | 1 | set | ||
| 6 | Transmission Rod 1000mm | H.1909.20.10C066 | 1 | pc | For oxygen bar of 1m, window width + frame width ≤ 2100mm |
Optional Components
| No. | Product Name | Product Code | Q'ty | Unit | Note |
| 7 | Middle Corner Transmission | AMCT53.00.031X | 1 | pc | Suitable for sash width 800mm, sash height 1200mm，supporting added top lock, lift handle life, lock security, and sealing |
| 8 | Anti-Collision Block | ALR53.00.38WA4 | 1 | pc | |
| 9 | Stainless Steel Screws | ALP18.00.38WA5 | 1 | pc | |
| 10 | Window Support Arm | ATR20.09C38WA5 | 1 | pc | / |
| 11 | SAS Magnetic Brake | AB100.01.06WA4 | 2 | set | / |
Sash Width：
525-1000mm
Sash Height：
780-2600mm
Max. Sash Weight：
100KG
